| Specification Model | WDW-H50 / WDW-H100 |
| Maximum test force (KN) | 50 / 100 |
| Level | Level 1 (can be customized to 0.5 on request) |
| Test force measurement range (FS) | 1% to 100% of the entire process without graduation |
| Relative error of test force value | ±1% or less |
| Test force resolution | 1/±300000 of the maximum test force |
| Deformation measurement range (FS) | 0.2%～100% |
| Relative error of deformation value | Within ±0.5% of the displayed value |
| Deformation resolution | 1/±300000 of the maximum deformation |
| Relative Error of Displacement Value | Within ±0.5% of the displayed value |
| Displacement resolution (µm) | 0.025 |
| Force control rate adjustment range (FS/S) | 0.01～5% |
| Relative error of force control rate | Within ±1% of the set value |
| Deformation rate adjustment range (FS/S) | 0.02%～5% |
| Relative error of deformation control rate | Within ±1% of the set value |
| Crossbar speed adjustment range (mm/min) | 0.01～200 |
| Constant force, constant deformation, constant displacement control range (FS) | 1%～100% |
| Constant force, constant deformation, constant displacement control accuracy | Within ±1% of the set value when the set value is <10%FS; within ±0.1% of the set value when the set value is ≥10%FS |
| Effective test space (mm) | 1500 |
| Effective test width (mm) | 1000 |
| Mainframe external dimensions (mm) | 1900×700×2350 / 1900×700×2850 |
| Power supply | 220V±10%，0.75kW / 220V±10%，1.5kW |
| Host weight (kg) | 1300 / 1400 |
